ODROID Lite is an open-source single-board computer. It is highly compact with a dimension of 69X48mm. It can run Android 4.4, Ubuntu, and Debian Image.

What can I do with ODROID Lite?

  • A computer
  • A wireless server
  • Games
  • Music and sounds
  • HD video
  • A speaker
  • Android
  • Scratch
  • Pretty much anything else, because Odroid Liteis open source

Who’s it for?

Odroid Lite is for anyone who wants to start creating with technology – not just consuming it. It's a simple, fun, useful tool that you can use to start taking control of the world around you.

Hardware specification


H3 Quad-core Cortex-A7 H.265/HEVC 4K


·Mali400MP2 GPU @600MHz
·Supports OpenGL ES 2.0

Memory (SDRAM)

512MB/1GB DDR3 (shared with GPU)

Onboard Storage

TF card (Max. 32GB) / MMC card slot

Onboard Network

10/100M Ethernet RJ45

Video Input

A CSI input connector Camera:

Supports 8-bit YUV422 CMOS sensor interface

Supports CCIR656 protocol for NTSC and PAL

Supports SM pixel camera sensor

Supports video capture solution up to 1080p@30fps

Video Outputs

Supports HDMI output with HDCP

Supports HDMI CEC

Supports HDMI 30 function

Supports simultaneous output of HDMI

Power Source

DC input can supply power, but USB OTG input don’t supply power

USB 2.0 Ports

Only One USB 2.0 HOST, one USB 2.0 OTG


Power Button(SW4)

Low-level peripherals

40 Pins Header


Power led & Status led



Supported OS

Android, Ubuntu, Debian Image

Interface definition

Product size

69 mm × 48mm



Motherboard Specification
Input Power 5V DC (Power adaptor available separately)

Odroid Lite - open-source single-board computer [99000]

  • Brand: Hard Kernel
  • Product Code: Odroid Lite - open-source single-board computer
  • Availability: In Stock
  • 34.49€

  • Ex Tax: 28.74€
